Electric heated and dry type (No water)

• Electrical dry-type (Heating medium: metals with high heat conductivity / Heat source: electric heater)

• Design pressure: 1.77MPa(17.7bar)

• Explosion proof: Class I, Division 1, Group D & Ex d IIB T3

• Electric power: 220V 1P 50/60Hz, 220V 3P 50/60Hz, 380V 3P 50/60Hz, Etc

• High quality and long-life electric heater

• Safety devices
  - Prevention of liquid LPG overflow with reset by mechanical float
  - LPG pressure safety valve: 1.76MPa(17.6bar)
  - Overheat protection by heater thermal switch

• Gas temperature & pressure gauge

• High corrosion resistance in comparison with wet type vaporizer using water as heating medium

• Installable in narrow space or wall by miniaturization and weight reduction

• Additional device for liquid LPG overflow prevention by solenoid valve and heater thermal switch - In case of electric power outage and heater low temperature

• Additional device for liquid LPG overflow prevention by LPG level switch

• CE(ATEX, PED) Approval

Capacity: LPG 100kg/hr

Type: Electric heated and Dry type

Design pressure: 1.77MPa

Electric power: 220V 1P(3P) 50(60)Hz / 380V 3P 50(60)Hz / Etc

Electric Heater: 15kw/h

LPG Inlet: ANSI #300 20A(3/4") Flanged end

LPG outlet: ANSI #300 25A(1") Flanged end

LPG Liquid prevention device by mechancial float type
Pressure safety valve 1pc: Rego Made in USA, Brass 1/2" Male, CE(PED)

Temperature controller 2pcs: Heater control / High temperature

Heater Temperature sensor 2pcs(4signals): Heater control / High temperature / Output signal(Sol' valve)

Gas Pressure gauge : STS304, CE(PED)

Gas temperature gauge

Bimetal temperature switch: High temperature of Heater

Explosion proof type control panel on Vaporizer: CE(ATEX)

Solenoid Valve of LPG inlet with CE(ATEX)

Temperature controller 3pcs: Heater control / High temperature / Solenoid valve

Packing details: Net/Gross Weight (kg): 80/128
Dimension (mm): 720W530L*1680H, 0.65CBM

Maker: Korea Gas Engineering & Made in Korea
