Electric heated and water bath type
Type: Electric with water bath
Electrical Parameters: 380V 3P 50(60)Hz
Heating Power: 4.5 - 180 kW/h
Design Pressure: 1.77 MPa
LPG Inlet: ANSI #300 20A(3/4")- 40A (1 1/2") with flange
LPG Outlet: ANSI #300 25A (1") - 80A (3") with flange
Mechanical float to prevent liquid LPG flow
1 pcs. Safety Valve: Rego, USA, brass male, CE(PED)
2 pcs. temperature regulators: Heating control / High temperature
2 pcs. temperature sensors (4 signals): Heating control / High temperature / Output signal (Solenoid valve)
Gas pressure gauge: STS304, CE(PED)
Gas thermometer, bimetal temperature switch
Solenoid valve at the liquid phase LPG inlet with CE(ATEX) certificate
3 pcs. temperature regulators: Heating control / High temperature / Solenoid valve
Control panel on the LPG Vaporizer in EX version
Manufacturer: Korea Gas Engineering & Made in Korea
1
Flange connection on the outlet
of the vaporized LPG phase from
the vaporizer.
2
Flange connection on the inlet of the liquid phase LPG to the vaporizer.
3
Electromagnetic valve on the inlet of the liquid phase LPG to the vaporizer.
1
Reset button for the float valve to the open position.
2
Flange connection on the outlet of the vaporized LPG phase from the vaporizer.
3
Location of the float valve blocker on the outlet of the vaporized LPG phase from the vaporizer.
